| document | model | rated voltage |
operating voltage range |
rated current |
rated input power |
speed | maximum air flow |
maximun air pressure |
noise | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 承认书 | 型号 | 额定定压 | 电压范围 | 额定电流 | 额定功率 | 转速 | 最大风量 | 最大风压 | 噪音 | |||
| 文档 | part no. | vdc | vdc | amp | watt | r.p.m | ㎥/min | cfm | pa | mmh2o | inh2o | db-a |
 |
yy8025l12-1 | 12 | yy8025l12-1 | 0.14 | 1.68 | 2500 | 0.85512 | 30.54 | 24.9 | 2.54 | 0.1 | 28.9 |
|
|
yy8025l24-1 | 24 | yy8025l24-1 | 0.07 | 1.68 | 2500 | 0.85512 | 30.54 | 24.9 | 2.54 | 0.1 | 28.9 |
|
|
yy8025m12-1 | 12 | yy8025m12-1 | 0.2 | 2.4 | 3000 | 1.02088 | 36.46 | 34.86 | 3.556 | 0.14 | 33.8 |
|
|
yy8025m24-1 | 24 | yy8025m24-1 | 0.11 | 2.64 | 3000 | 1.02088 | 36.46 | 34.86 | 3.556 | 0.14 | 33.8 |
|
|
yy8025h12-1 | 12 | yy8025h12-1 | 0.26 | 3.12 | 3500 | 1.18636 | 42.37 | 47.31 | 4.826 | 0.19 | 38.5 |
|
|
yy8025h24-1 | 24 | yy8025h24-1 | 0.13 | 3.12 | 3500 | 1.18636 | 42.37 | 47.31 | 4.826 | 0.19 | 38.5 |
|
|
yy8025h48-1 | 48 | yy8025h48-1 | 0.06 | 2.88 | 3500 | 1.18636 | 42.37 | 47.31 | 4.826 | 0.19 | 38.5 |
|
|
yy8025h12-hh-1 | 12 | yy8025h12-hh-1 | 0.32 | 3.84 | 4000 | 1.35884 | 48.53 | 59.76 | 6.096 | 0.24 | 41 |
|
|
yy8025h24-hh-1 | 24 | yy8025h24-hh-1 | 0.16 | 3.84 | 4000 | 1.35884 | 48.53 | 59.76 | 6.096 | 0.24 | 41 |
|
|
yy8025h48-hh-1 | 48 | yy8025h48-hh-1 | 0.09 | 4.32 | 4000 | 1.35884 | 48.53 | 59.76 | 6.096 | 0.24 | 41 |
|
|
yy8025h24-vh-1 | 24 | yy8025h24-vh-1 | 0.23 | 5.52 | 4500 | 1.53076 | 54.67 | 74.7 | 7.62 | 0.3 | 44.3 |
|
|
yy8025h48-vh-1 | 48 | yy8025h48-vh-1 | 0.1 | 4.8 | 4500 | 1.53076 | 54.67 | 74.7 | 7.62 | 0.3 | 44.3 |
